初始化便是构建 kclist_head 链表的一个过程，链表中每一个成员对应一个 PT_LOAD segment。
在读操作的时候再用 elf 的 PT_LOAD segment 呈现这些成员。

static int __init proc_kcore_init(void){/ (1) 创建 /proc/kcore 文件 / proc_root_kcore = proc_create(\公众kcore\"大众, S_IRUSR, , &kcore_proc_ops);if (!proc_root_kcore) { pr_err(\"大众couldn't create /proc/kcore\n\公众);return 0; / Always returns 0. / }/ Store text area if it's special // (2) 将内核代码段 _text 加入kclist_head链表，kclist_head链表中每一个成员对应一个 PT_LOAD segment / proc_kcore_text_init();/ Store vmalloc area // (3) 将 VMALLOC 段内存加入kclist_head链表 / kclist_add(&kcore_vmalloc, (void )VMALLOC_START, VMALLOC_END - VMALLOC_START, KCORE_VMALLOC);/ (4) 将 MODULES_VADDR 模块内存加入kclist_head链表 / add_modules_range();/ Store direct-map area from physical memory map // (5) 遍历系统内存布局表，将有效内存加入kclist_head链表 / kcore_update_ram(); register_hotmemory_notifier(&kcore_callback_nb);return 0;}static int kcore_update_ram(void){ LIST_HEAD(list); LIST_HEAD(garbage);int nphdr;size_t phdrs_len, notes_len, data_offset;struct kcore_list tmp, pos;int ret = 0; down_write(&kclist_lock);if (!xchg(&kcore_need_update, 0))goto out;/ (5.1) 遍历系统内存布局表，将符合`IORESOURCE_SYSTEM_RAM | IORESOURCE_BUSY`内存加入list链表 / ret = kcore_ram_list(&list);if (ret) {/ Couldn't get the RAM list, try again next time. / WRITE_ONCE(kcore_need_update, 1); list_splice_tail(&list, &garbage);goto out; }/ (5.2) 删除掉原有 kclist_head 链表中的 KCORE_RAM/KCORE_VMEMMAP 区域，由于全局链表中已经覆盖了 / list_for_each_entry_safe(pos, tmp, &kclist_head, list) {if (pos->type == KCORE_RAM || pos->type == KCORE_VMEMMAP) list_move(&pos->list, &garbage); }/ (5.3) 将原有 kclist_head 链表 和全局链表 list 拼接到一起 / list_splice_tail(&list, &kclist_head);/ (5.4) 更新 kclist_head 链表的成员个数，一个成员代表一个 PT_LOAD segment。
打算 PT_NOTE segment 的长度 打算 `/proc/kcore` 文件的长度，这个长度是个虚值，最大是虚拟地址的最大范围 / proc_root_kcore->size = get_kcore_size(&nphdr, &phdrs_len, &notes_len, &data_offset);out: up_write(&kclist_lock);/ (5.5) 开释掉上面删除的链表成员占用的空间 / list_for_each_entry_safe(pos, tmp, &garbage, list) { list_del(&pos->list); kfree(pos); }return ret;}

个中的一个关键从遍历系统内存布局表，关键代码如下：

kcore_ram_list() → walk_system_ram_range():int walk_system_ram_range(unsigned long start_pfn, unsigned long nr_pages,void arg, int (func)(unsigned long, unsigned long, void )){resource_size_t start, end;unsigned long flags;struct resource res;unsigned long pfn, end_pfn;int ret = -EINVAL; start = (u64) start_pfn << PAGE_SHIFT; end = ((u64)(start_pfn + nr_pages) << PAGE_SHIFT) - 1;/ (5.1.1) 从 iomem_resource 链表中查找符合 IORESOURCE_SYSTEM_RAM | IORESOURCE_BUSY 的资源段 / flags = IORESOURCE_SYSTEM_RAM | IORESOURCE_BUSY;while (start < end && !find_next_iomem_res(start, end, flags, IORES_DESC_NONE,false, &res)) { pfn = PFN_UP(res.start); end_pfn = PFN_DOWN(res.end + 1);if (end_pfn > pfn) ret = (func)(pfn, end_pfn - pfn, arg);if (ret)break; start = res.end + 1; }return ret;}

实在就相称于以下命令：

$ sudo cat /proc/iomem | grep \"大众System RAM\"大众00001000-0009e7ff : System RAM00100000-7fedffff : System RAM7ff00000-7fffffff : System RAM读取 elf core

准备好数据往后，还是在读 /proc/kcore 文件时，以 elf core 的格式呈现。

static const struct proc_ops kcore_proc_ops = { .proc_read = read_kcore, .proc_open = open_kcore, .proc_release = release_kcore, .proc_lseek = default_llseek,};↓static ssize_tread_kcore(struct file file, char __user buffer, size_t buflen, loff_t fpos){char buf = file->private_data;size_t phdrs_offset, notes_offset, data_offset;size_t phdrs_len, notes_len;struct kcore_list m;size_t tsz;int nphdr;unsigned long start;size_t orig_buflen = buflen;int ret = 0; down_read(&kclist_lock);/ (1) 获取到PT_LOAD segment个数、PT_NOTE segment 的长度等信息，开始动态布局 elf core 文件了 / get_kcore_size(&nphdr, &phdrs_len, &notes_len, &data_offset); phdrs_offset = sizeof(struct elfhdr); notes_offset = phdrs_offset + phdrs_len;/ ELF file header. // (2) 布局 ELF 文件头，并拷贝给给用户态读内存 /if (buflen && fpos < sizeof(struct elfhdr)) {struct elfhdr ehdr = { .e_ident = { [EI_MAG0] = ELFMAG0, [EI_MAG1] = ELFMAG1, [EI_MAG2] = ELFMAG2, [EI_MAG3] = ELFMAG3, [EI_CLASS] = ELF_CLASS, [EI_DATA] = ELF_DATA, [EI_VERSION] = EV_CURRENT, [EI_OSABI] = ELF_OSABI, }, .e_type = ET_CORE, .e_machine = ELF_ARCH, .e_version = EV_CURRENT, .e_phoff = sizeof(struct elfhdr), .e_flags = ELF_CORE_EFLAGS, .e_ehsize = sizeof(struct elfhdr), .e_phentsize = sizeof(struct elf_phdr), .e_phnum = nphdr, }; tsz = min_t(size_t, buflen, sizeof(struct elfhdr) - fpos);if (copy_to_user(buffer, (char )&ehdr + fpos, tsz)) { ret = -EFAULT;goto out; } buffer += tsz; buflen -= tsz; fpos += tsz; }/ ELF program headers. // (3) 布局 ELF program 头，并拷贝给给用户态读内存 /if (buflen && fpos < phdrs_offset + phdrs_len) {struct elf_phdr phdrs, phdr; phdrs = kzalloc(phdrs_len, GFP_KERNEL);if (!phdrs) { ret = -ENOMEM;goto out; }/ (3.1) PT_NOTE segment 不须要物理地址和虚拟地址 / phdrs[0].p_type = PT_NOTE; phdrs[0].p_offset = notes_offset; phdrs[0].p_filesz = notes_len; phdr = &phdrs[1];/ (3.2) 逐个打算 PT_LOAD segment 的物理地址、虚拟地址和长度 / list_for_each_entry(m, &kclist_head, list) { phdr->p_type = PT_LOAD; phdr->p_flags = PF_R | PF_W | PF_X; phdr->p_offset = kc_vaddr_to_offset(m->addr) + data_offset;if (m->type == KCORE_REMAP) phdr->p_vaddr = (size_t)m->vaddr;else phdr->p_vaddr = (size_t)m->addr;if (m->type == KCORE_RAM || m->type == KCORE_REMAP) phdr->p_paddr = __pa(m->addr);else if (m->type == KCORE_TEXT) phdr->p_paddr = __pa_symbol(m->addr);else phdr->p_paddr = (elf_addr_t)-1; phdr->p_filesz = phdr->p_memsz = m->size; phdr->p_align = PAGE_SIZE; phdr++; } tsz = min_t(size_t, buflen, phdrs_offset + phdrs_len - fpos);if (copy_to_user(buffer, (char )phdrs + fpos - phdrs_offset, tsz)) { kfree(phdrs); ret = -EFAULT;goto out; } kfree(phdrs); buffer += tsz; buflen -= tsz; fpos += tsz; }/ ELF note segment. // (4) 布局 PT_NOTE segment，并拷贝给给用户态读内存 /if (buflen && fpos < notes_offset + notes_len) {struct elf_prstatus prstatus = {};struct elf_prpsinfo prpsinfo = { .pr_sname = 'R', .pr_fname = \公众vmlinux\公众, };char notes;size_t i = 0; strlcpy(prpsinfo.pr_psargs, saved_command_line,sizeof(prpsinfo.pr_psargs)); notes = kzalloc(notes_len, GFP_KERNEL);if (!notes) { ret = -ENOMEM;goto out; }/ (4.1) 添加 NT_PRSTATUS / append_kcore_note(notes, &i, CORE_STR, NT_PRSTATUS, &prstatus,sizeof(prstatus));/ (4.2) 添加 NT_PRPSINFO / append_kcore_note(notes, &i, CORE_STR, NT_PRPSINFO, &prpsinfo,sizeof(prpsinfo));/ (4.3) 添加 NT_TASKSTRUCT / append_kcore_note(notes, &i, CORE_STR, NT_TASKSTRUCT, current, arch_task_struct_size);/ vmcoreinfo_size is mostly constant after init time, but it can be changed by crash_save_vmcoreinfo(). Racing here with a panic on another CPU before the machine goes down is insanely unlikely, but it's better to not leave potential buffer overflows lying around, regardless. Vmcoreinfo_size在初始化后基本保持不变，但可以通过crash_save_vmcoreinfo()修正。
在机器宕机之前，在另一个CPU上涌现惶恐是不太可能的，但无论如何，最好不要让潜在的缓冲区溢出到处存在。
// (4.4) 添加 VMCOREINFO / append_kcore_note(notes, &i, VMCOREINFO_NOTE_NAME, 0, vmcoreinfo_data, min(vmcoreinfo_size, notes_len - i)); tsz = min_t(size_t, buflen, notes_offset + notes_len - fpos);if (copy_to_user(buffer, notes + fpos - notes_offset, tsz)) { kfree(notes); ret = -EFAULT;goto out; } kfree(notes); buffer += tsz; buflen -= tsz; fpos += tsz; }/ Check to see if our file offset matches with any of the addresses in the elf_phdr on our list. / start = kc_offset_to_vaddr(fpos - data_offset);if ((tsz = (PAGE_SIZE - (start & ~PAGE_MASK))) > buflen) tsz = buflen; m = ;/ (5) 布局 PT_LOAD segment，并拷贝给给用户态读内存 /while (buflen) {/ If this is the first iteration or the address is not within the previous entry, search for a matching entry. /if (!m || start < m->addr || start >= m->addr + m->size) { list_for_each_entry(m, &kclist_head, list) {if (start >= m->addr && start < m->addr + m->size)break; } }if (&m->list == &kclist_head) {if (clear_user(buffer, tsz)) { ret = -EFAULT;goto out; } m = ; / skip the list anchor / } else if (!pfn_is_ram(__pa(start) >> PAGE_SHIFT)) {if (clear_user(buffer, tsz)) { ret = -EFAULT;goto out; } } else if (m->type == KCORE_VMALLOC) { vread(buf, (char )start, tsz);/ we have to zero-fill user buffer even if no read /if (copy_to_user(buffer, buf, tsz)) { ret = -EFAULT;goto out; } } else if (m->type == KCORE_USER) {/ User page is handled prior to normal kernel page: /if (copy_to_user(buffer, (char )start, tsz)) { ret = -EFAULT;goto out; } } else {if (kern_addr_valid(start)) {/ Using bounce buffer to bypass the hardened user copy kernel text checks. /if (copy_from_kernel_nofault(buf, (void )start, tsz)) {if (clear_user(buffer, tsz)) { ret = -EFAULT;goto out; } } else {if (copy_to_user(buffer, buf, tsz)) { ret = -EFAULT;goto out; } } } else {if (clear_user(buffer, tsz)) { ret = -EFAULT;goto out; } } } buflen -= tsz; fpos += tsz; buffer += tsz; start += tsz; tsz = (buflen > PAGE_SIZE ? PAGE_SIZE : buflen); }out: up_read(&kclist_lock);if (ret)return ret;return orig_buflen - buflen;}/proc/vmcore

/proc/vmcore 是在 crash kernel 中把 normal kernel 的内存仿照成一个 elf core 文件。

它的文件格式布局是和上一节的 /proc/kcore 是类似的，不同的是它的数据准备事情是分成两部分完成的：

下面我们就来详细剖析详细的过程。

在系统发生故障时状态是很不稳定的，韶光也是很紧急的，以是我们在 normal kernel 中就尽可能早的把 /proc/vomcore 文件的 elf header 数据准备好。
虽然 normal kernel 不会呈现 /proc/vmcore，只会在 crash kernel 中呈现。

在 kexec_tools 利用 kexec_file_load() 系统调用加载 crash kernel 时，就顺带把 /proc/vmcore 的 elf header 须要的大部分数据准备好了：

kexec_file_load() → kimage_file_alloc_init() → kimage_file_prepare_segments() → arch_kexec_kernel_image_load() → image->fops->load() → kexec_bzImage64_ops.load() → bzImage64_load() → crash_load_segments() → prepare_elf_headers() → crash_prepare_elf64_headers()：static int prepare_elf_headers(struct kimage image, void addr,unsigned long sz){struct crash_mem cmem;int ret;/ (1) 遍历系统内存布局表统计有效内存区域的个数，根据个数分配 cmem 空间 / cmem = fill_up_crash_elf_data();if (!cmem)return -ENOMEM;/ (2) 再次遍历系统内存布局表统计有效内存区域，记录到 cmem 空间 / ret = walk_system_ram_res(0, -1, cmem, prepare_elf64_ram_headers_callback);if (ret)goto out;/ Exclude unwanted mem ranges // (3) 打消掉一些不会利用的内存区域 / ret = elf_header_exclude_ranges(cmem);if (ret)goto out;/ By default prepare 64bit headers // (4) 开始布局 elf header / ret = crash_prepare_elf64_headers(cmem, IS_ENABLED(CONFIG_X86_64), addr, sz);out: vfree(cmem);return ret;}int crash_prepare_elf64_headers(struct crash_mem mem, int kernel_map,void addr, unsigned long sz){ Elf64_Ehdr ehdr; Elf64_Phdr phdr;unsigned long nr_cpus = num_possible_cpus(), nr_phdr, elf_sz;unsigned char buf;unsigned int cpu, i;unsigned long long notes_addr;unsigned long mstart, mend;/ extra phdr for vmcoreinfo elf note / nr_phdr = nr_cpus + 1; nr_phdr += mem->nr_ranges;/ kexec-tools creates an extra PT_LOAD phdr for kernel text mapping area (for example, ffffffff80000000 - ffffffffa0000000 on x86_64). I think this is required by tools like gdb. So same physical memory will be mapped in two elf headers. One will contain kernel text virtual addresses and other will have __va(physical) addresses. / nr_phdr++; elf_sz = sizeof(Elf64_Ehdr) + nr_phdr sizeof(Elf64_Phdr); elf_sz = ALIGN(elf_sz, ELF_CORE_HEADER_ALIGN); buf = vzalloc(elf_sz);if (!buf)return -ENOMEM;/ (4.1) 布局 ELF 文件头 / ehdr = (Elf64_Ehdr )buf; phdr = (Elf64_Phdr )(ehdr + 1);memcpy(ehdr->e_ident, ELFMAG, SELFMAG); ehdr->e_ident[EI_CLASS] = ELFCLASS64; ehdr->e_ident[EI_DATA] = ELFDATA2LSB; ehdr->e_ident[EI_VERSION] = EV_CURRENT; ehdr->e_ident[EI_OSABI] = ELF_OSABI;memset(ehdr->e_ident + EI_PAD, 0, EI_NIDENT - EI_PAD); ehdr->e_type = ET_CORE; ehdr->e_machine = ELF_ARCH; ehdr->e_version = EV_CURRENT; ehdr->e_phoff = sizeof(Elf64_Ehdr); ehdr->e_ehsize = sizeof(Elf64_Ehdr); ehdr->e_phentsize = sizeof(Elf64_Phdr);/ Prepare one phdr of type PT_NOTE for each present cpu // (4.2) 布局 ELF program 头， 每个 cpu 独立布局一个 PT_LOAD segment segment 的数据存放在 per_cpu_ptr(crash_notes, cpu) 变量当中 把稳 crash_notes 中目前还没有数据，当前只是记录了物理地址。
只有在 crash 发生往后，才会实际往里面存储数据 / for_each_present_cpu(cpu) { phdr->p_type = PT_NOTE; notes_addr = per_cpu_ptr_to_phys(per_cpu_ptr(crash_notes, cpu)); phdr->p_offset = phdr->p_paddr = notes_addr; phdr->p_filesz = phdr->p_memsz = sizeof(note_buf_t); (ehdr->e_phnum)++; phdr++; }/ Prepare one PT_NOTE header for vmcoreinfo // (4.3) 布局 ELF program 头，VMCOREINFO 独立布局一个 PT_LOAD segment 把稳当前只是记录了 vmcoreinfo_note 的物理地址，实际数据也是分几部分更新的 / phdr->p_type = PT_NOTE; phdr->p_offset = phdr->p_paddr = paddr_vmcoreinfo_note(); phdr->p_filesz = phdr->p_memsz = VMCOREINFO_NOTE_SIZE; (ehdr->e_phnum)++; phdr++;/ Prepare PT_LOAD type program header for kernel text region // (4.4) 布局 ELF program 头，内核代码段对应的 PT_LOAD segment /if (kernel_map) { phdr->p_type = PT_LOAD; phdr->p_flags = PF_R|PF_W|PF_X; phdr->p_vaddr = (unsigned long) _text; phdr->p_filesz = phdr->p_memsz = _end - _text; phdr->p_offset = phdr->p_paddr = __pa_symbol(_text); ehdr->e_phnum++; phdr++; }/ Go through all the ranges in mem->ranges[] and prepare phdr // (4.5) 遍历 cmem，把系统中的有效内存创建成 PT_LOAD segment /for (i = 0; i < mem->nr_ranges; i++) { mstart = mem->ranges[i].start; mend = mem->ranges[i].end; phdr->p_type = PT_LOAD; phdr->p_flags = PF_R|PF_W|PF_X; phdr->p_offset = mstart; phdr->p_paddr = mstart; phdr->p_vaddr = (unsigned long) __va(mstart); phdr->p_filesz = phdr->p_memsz = mend - mstart + 1; phdr->p_align = 0; ehdr->e_phnum++; phdr++; pr_debug(\"大众Crash PT_LOAD elf header. phdr=%p vaddr=0x%llx, paddr=0x%llx, sz=0x%llx e_phnum=%d p_offset=0x%llx\n\"大众, phdr, phdr->p_vaddr, phdr->p_paddr, phdr->p_filesz, ehdr->e_phnum, phdr->p_offset); } addr = buf; sz = elf_sz;return 0;}

1. crash_notes 数据的更新

只有在发生 panic 往后，才会往 crash_notes 中保存实际的 CPU 寄存器数据。
其更新过程如下：

__crash_kexec() → machine_crash_shutdown() → crash_save_cpu()：ipi_cpu_crash_stop() → crash_save_cpu()：void crash_save_cpu(struct pt_regs regs, int cpu){struct elf_prstatus prstatus; u32 buf;if ((cpu < 0) || (cpu >= nr_cpu_ids))return;/ Using ELF notes here is opportunistic. I need a well defined structure format for the data I pass, and I need tags on the data to indicate what information I have squirrelled away. ELF notes happen to provide all of that, so there is no need to invent something new. / buf = (u32 )per_cpu_ptr(crash_notes, cpu);if (!buf)return;/ (1) 清零 /memset(&prstatus, 0, sizeof(prstatus));/ (2) 保存 pid / prstatus.pr_pid = current->pid;/ (3) 保存 寄存器 / elf_core_copy_kernel_regs(&prstatus.pr_reg, regs);/ (4) 以 elf_note 格式存储到 crash_notes 中 / buf = append_elf_note(buf, KEXEC_CORE_NOTE_NAME, NT_PRSTATUS, &prstatus, sizeof(prstatus));/ (5) 追加一个全零的 elf_note 当作结尾 / final_note(buf);}

2. vmcoreinfo_note 数据的更新

vmcoreinfo_note 分成两部分来更新：

static int __init crash_save_vmcoreinfo_init(void){/ (1.1) 分配 vmcoreinfo_data 空间 / vmcoreinfo_data = (unsigned char )get_zeroed_page(GFP_KERNEL);if (!vmcoreinfo_data) { pr_warn(\"大众Memory allocation for vmcoreinfo_data failed\n\公众);return -ENOMEM; }/ (1.2) 分配 vmcoreinfo_note 空间 / vmcoreinfo_note = alloc_pages_exact(VMCOREINFO_NOTE_SIZE, GFP_KERNEL | __GFP_ZERO);if (!vmcoreinfo_note) { free_page((unsigned long)vmcoreinfo_data); vmcoreinfo_data = ; pr_warn(\"大众Memory allocation for vmcoreinfo_note failed\n\"大众);return -ENOMEM; }/ (2.1) 把系统的各种关键信息利用 VMCOREINFO_xxx 一系列宏，以字符串的形式保持到 vmcoreinfo_data / VMCOREINFO_OSRELEASE(init_uts_ns.name.release); VMCOREINFO_PAGESIZE(PAGE_SIZE); VMCOREINFO_SYMBOL(init_uts_ns); VMCOREINFO_SYMBOL(node_online_map);#ifdef CONFIG_MMU VMCOREINFO_SYMBOL_ARRAY(swapper_pg_dir);#endif VMCOREINFO_SYMBOL(_stext); VMCOREINFO_SYMBOL(vmap_area_list);#ifndef CONFIG_NEED_MULTIPLE_NODES VMCOREINFO_SYMBOL(mem_map); VMCOREINFO_SYMBOL(contig_page_data);#endif#ifdef CONFIG_SPARSEMEM VMCOREINFO_SYMBOL_ARRAY(mem_section); VMCOREINFO_LENGTH(mem_section, NR_SECTION_ROOTS); VMCOREINFO_STRUCT_SIZE(mem_section); VMCOREINFO_OFFSET(mem_section, section_mem_map);#endif VMCOREINFO_STRUCT_SIZE(page); VMCOREINFO_STRUCT_SIZE(pglist_data); VMCOREINFO_STRUCT_SIZE(zone); VMCOREINFO_STRUCT_SIZE(free_area); VMCOREINFO_STRUCT_SIZE(list_head); VMCOREINFO_SIZE(nodemask_t); VMCOREINFO_OFFSET(page, flags); VMCOREINFO_OFFSET(page, _refcount); VMCOREINFO_OFFSET(page, mapping); VMCOREINFO_OFFSET(page, lru); VMCOREINFO_OFFSET(page, _mapcount); VMCOREINFO_OFFSET(page, private); VMCOREINFO_OFFSET(page, compound_dtor); VMCOREINFO_OFFSET(page, compound_order); VMCOREINFO_OFFSET(page, compound_head); VMCOREINFO_OFFSET(pglist_data, node_zones); VMCOREINFO_OFFSET(pglist_data, nr_zones);#ifdef CONFIG_FLAT_NODE_MEM_MAP VMCOREINFO_OFFSET(pglist_data, node_mem_map);#endif VMCOREINFO_OFFSET(pglist_data, node_start_pfn); VMCOREINFO_OFFSET(pglist_data, node_spanned_pages); VMCOREINFO_OFFSET(pglist_data, node_id); VMCOREINFO_OFFSET(zone, free_area); VMCOREINFO_OFFSET(zone, vm_stat); VMCOREINFO_OFFSET(zone, spanned_pages); VMCOREINFO_OFFSET(free_area, free_list); VMCOREINFO_OFFSET(list_head, next); VMCOREINFO_OFFSET(list_head, prev); VMCOREINFO_OFFSET(vmap_area, va_start); VMCOREINFO_OFFSET(vmap_area, list); VMCOREINFO_LENGTH(zone.free_area, MAX_ORDER); log_buf_vmcoreinfo_setup(); VMCOREINFO_LENGTH(free_area.free_list, MIGRATE_TYPES); VMCOREINFO_NUMBER(NR_FREE_PAGES); VMCOREINFO_NUMBER(PG_lru); VMCOREINFO_NUMBER(PG_private); VMCOREINFO_NUMBER(PG_swapcache); VMCOREINFO_NUMBER(PG_swapbacked); VMCOREINFO_NUMBER(PG_slab);#ifdef CONFIG_MEMORY_FAILURE VMCOREINFO_NUMBER(PG_hwpoison);#endif VMCOREINFO_NUMBER(PG_head_mask);#define PAGE_BUDDY_MAPCOUNT_VALUE (~PG_buddy) VMCOREINFO_NUMBER(PAGE_BUDDY_MAPCOUNT_VALUE);#ifdef CONFIG_HUGETLB_PAGE VMCOREINFO_NUMBER(HUGETLB_PAGE_DTOR);#define PAGE_OFFLINE_MAPCOUNT_VALUE (~PG_offline) VMCOREINFO_NUMBER(PAGE_OFFLINE_MAPCOUNT_VALUE);#endif/ (2.2) 补充一些架构干系的 vmcoreinfo / arch_crash_save_vmcoreinfo();/ (3) 把 vmcoreinfo_data 中保存的数据以 elf_note 的形式保存到 vmcoreinfo_note 中 / update_vmcoreinfo_note();return 0;}

__crash_kexec() → crash_save_vmcoreinfo()：void crash_save_vmcoreinfo(void){if (!vmcoreinfo_note)return;/ Use the safe copy to generate vmcoreinfo note if have /if (vmcoreinfo_data_safecopy) vmcoreinfo_data = vmcoreinfo_data_safecopy;/ (1) 补充 \"大众CRASHTIME=xxx\公众 信息 / vmcoreinfo_append_str(\公众CRASHTIME=%lld\n\"大众, ktime_get_real_seconds()); update_vmcoreinfo_note();}

vmcoreinfo 对应 readelf -n xxx 读出的数据：

$ readelf -n vmcore.202106170650 Displaying notes found at file offset 0x00001000 with length 0x00000ac8: Owner Data size Description CORE 0x00000150 NT_PRSTATUS (prstatus structure) CORE 0x00000150 NT_PRSTATUS (prstatus structure) VMCOREINFO 0x000007e6 Unknown note type: (0x00000000) description data: 4f 53 52 45 4c 45 41 53 45 3d 35 2e 38 2e 30// description data 对应 ascii：OSRELEASE=5.8.0-43-genericPAGESIZE=4096SYMBOL(init_uts_ns)=ffffffffa5014620SYMBOL(node_online_map)=ffffffffa5276720SYMBOL(swapper_pg_dir)=ffffffffa500a000SYMBOL(_stext)=ffffffffa3a00000SYMBOL(vmap_area_list)=ffffffffa50f2560SYMBOL(mem_section)=ffff91673ffd2000LENGTH(mem_section)=2048SIZE(mem_section)=16OFFSET(mem_section.section_mem_map)=0SIZE(page)=64SIZE(pglist_data)=171968SIZE(zone)=1472SIZE(free_area)=88...CRASHTIME=1623937823准备 cmdline (运行在 normal kernel)

准备好的 elf header 数据怎么通报给 crash kernel 呢？是通过 cmdline 来进行通报的：

kexec_file_load() → kimage_file_alloc_init() → kimage_file_prepare_segments() → arch_kexec_kernel_image_load() → image->fops->load() → kexec_bzImage64_ops.load() → bzImage64_load() → setup_cmdline():static int setup_cmdline(struct kimage image, struct boot_params params,unsigned long bootparams_load_addr,unsigned long cmdline_offset, char cmdline,unsigned long cmdline_len){char cmdline_ptr = ((char )params) + cmdline_offset;unsigned long cmdline_ptr_phys, len = 0;uint32_t cmdline_low_32, cmdline_ext_32;/ (1) 在 crask kernel 的 cmdline 中追加参数：\"大众elfcorehdr=0x%lx \"大众 /if (image->type == KEXEC_TYPE_CRASH) { len = sprintf(cmdline_ptr,\公众elfcorehdr=0x%lx \"大众, image->arch.elf_load_addr); }memcpy(cmdline_ptr + len, cmdline, cmdline_len); cmdline_len += len; cmdline_ptr[cmdline_len - 1] = '\0'; pr_debug(\"大众Final command line is: %s\n\公众, cmdline_ptr); cmdline_ptr_phys = bootparams_load_addr + cmdline_offset; cmdline_low_32 = cmdline_ptr_phys & 0xffffffffUL; cmdline_ext_32 = cmdline_ptr_phys >> 32; params->hdr.cmd_line_ptr = cmdline_low_32;if (cmdline_ext_32) params->ext_cmd_line_ptr = cmdline_ext_32;return 0;}启动 crash kernel (运行在 normal kernel)

在 normal kernel 发生 panic 往后会 跳转到 carsh kernel：

die() → crash_kexec() → __crash_kexec() → machine_kexec()吸收 elfheadr (运行在 crash kernel)

在 carsh kernel 中首先会吸收到 normal kernel 在 cmdline 中通报过来的 vmcore 文件的 elf header 信息：

static int __init setup_elfcorehdr(char arg){char end;if (!arg)return -EINVAL; elfcorehdr_addr = memparse(arg, &end);if (end == '@') { elfcorehdr_size = elfcorehdr_addr; elfcorehdr_addr = memparse(end + 1, &end); }return end > arg ? 0 : -EINVAL;}early_param(\公众elfcorehdr\公众, setup_elfcorehdr);解析整理 elfheadr (运行在 crash kernel)

然后会读取 vmcore 文件的 elf header 信息，并进行解析和整理：

static int __init vmcore_init(void){int rc = 0;/ Allow architectures to allocate ELF header in 2nd kernel / rc = elfcorehdr_alloc(&elfcorehdr_addr, &elfcorehdr_size);if (rc)return rc;/ If elfcorehdr= has been passed in cmdline or created in 2nd kernel, then capture the dump. /if (!(is_vmcore_usable()))return rc;/ (1) 解析 normal kernel 通报过来的 elf header 信息 / rc = parse_crash_elf_headers();if (rc) { pr_warn(\"大众Kdump: vmcore not initialized\n\公众);return rc; } elfcorehdr_free(elfcorehdr_addr); elfcorehdr_addr = ELFCORE_ADDR_ERR;/ (2) 创建 /proc/vmcore 文件接口 / proc_vmcore = proc_create(\"大众vmcore\"大众, S_IRUSR, , &vmcore_proc_ops);if (proc_vmcore) proc_vmcore->size = vmcore_size;return 0;}fs_initcall(vmcore_init);↓parse_crash_elf_headers()↓static int __init parse_crash_elf64_headers(void){int rc=0; Elf64_Ehdr ehdr; u64 addr; addr = elfcorehdr_addr;/ Read Elf header // (1.1) 读出通报过来的 elf header 信息 把稳：涉及到读另一个别系的内存，我们须要对物理地址进行ioremap_cache() 建立映射往后才能读取 后续的很多地方都因此这种办法来读取 / rc = elfcorehdr_read((char )&ehdr, sizeof(Elf64_Ehdr), &addr);if (rc < 0)return rc;/ Do some basic Verification. // (1.2) 对读出的 elf header 信息进行一些合法性判断，防止被毁坏 /if (memcmp(ehdr.e_ident, ELFMAG, SELFMAG) != 0 || (ehdr.e_type != ET_CORE) || !vmcore_elf64_check_arch(&ehdr) || ehdr.e_ident[EI_CLASS] != ELFCLASS64 || ehdr.e_ident[EI_VERSION] != EV_CURRENT || ehdr.e_version != EV_CURRENT || ehdr.e_ehsize != sizeof(Elf64_Ehdr) || ehdr.e_phentsize != sizeof(Elf64_Phdr) || ehdr.e_phnum == 0) { pr_warn(\公众Warning: Core image elf header is not sane\n\"大众);return -EINVAL; }/ Read in all elf headers. // (1.3) 在crash kernel 上分配两个buffer，准备吧数据读到本地 elfcorebuf 用来存储 elf header + elf program header elfnotes_buf 用来存储 PT_NOTE segment / elfcorebuf_sz_orig = sizeof(Elf64_Ehdr) + ehdr.e_phnum sizeof(Elf64_Phdr); elfcorebuf_sz = elfcorebuf_sz_orig; elfcorebuf = (void )__get_free_pages(GFP_KERNEL | __GFP_ZERO, get_order(elfcorebuf_sz_orig));if (!elfcorebuf)return -ENOMEM; addr = elfcorehdr_addr;/ (1.4) 把全体 elf header + elf program header 读取到 elfcorebuf / rc = elfcorehdr_read(elfcorebuf, elfcorebuf_sz_orig, &addr);if (rc < 0)goto fail;/ Merge all PT_NOTE headers into one. // (1.5) 整理数据把多个 PT_NOTE 合并成一个，并且把 PT_NOTE 数据拷贝到 elfnotes_buf / rc = merge_note_headers_elf64(elfcorebuf, &elfcorebuf_sz, &elfnotes_buf, &elfnotes_sz);if (rc)goto fail;/ (1.6) 逐个调试 PT_LOAD segment 掌握头，让每个 segment 符合 page 对齐 / rc = process_ptload_program_headers_elf64(elfcorebuf, elfcorebuf_sz, elfnotes_sz, &vmcore_list);if (rc)goto fail;/ (1.7) 合营上一步的 page 对齐调度，打算 vmcore_list 链表中的 offset 偏移 / set_vmcore_list_offsets(elfcorebuf_sz, elfnotes_sz, &vmcore_list);return 0;fail: free_elfcorebuf();return rc;}↓static int __init merge_note_headers_elf64(char elfptr, size_t elfsz,char notes_buf, size_t notes_sz){int i, nr_ptnote=0, rc=0;char tmp; Elf64_Ehdr ehdr_ptr; Elf64_Phdr phdr; u64 phdr_sz = 0, note_off; ehdr_ptr = (Elf64_Ehdr )elfptr;/ (1.5.1) 更新每个独立 PT_NOTE 的长度，去除尾部全零 elf_note / rc = update_note_header_size_elf64(ehdr_ptr);if (rc < 0)return rc;/ (1.5.2) 打算 所有 PT_NOTE 数据加起来的总长度 / rc = get_note_number_and_size_elf64(ehdr_ptr, &nr_ptnote, &phdr_sz);if (rc < 0)return rc; notes_sz = roundup(phdr_sz, PAGE_SIZE); notes_buf = vmcore_alloc_buf(notes_sz);if (!notes_buf)return -ENOMEM;/ (1.5.3) 把所有 PT_NOTE 数据拷贝到一起，拷贝到 notes_buf 中 / rc = copy_notes_elf64(ehdr_ptr, notes_buf);if (rc < 0)return rc;/ Prepare merged PT_NOTE program header. // (1.5.4) 创建一个新的 PT_NOTE 掌握构造来寻址 notes_buf / phdr.p_type = PT_NOTE; phdr.p_flags = 0; note_off = sizeof(Elf64_Ehdr) + (ehdr_ptr->e_phnum - nr_ptnote +1) sizeof(Elf64_Phdr); phdr.p_offset = roundup(note_off, PAGE_SIZE); phdr.p_vaddr = phdr.p_paddr = 0; phdr.p_filesz = phdr.p_memsz = phdr_sz; phdr.p_align = 0;/ Add merged PT_NOTE program header// (1.5.5) 拷贝新的 PT_NOTE 掌握构造 / tmp = elfptr + sizeof(Elf64_Ehdr);memcpy(tmp, &phdr, sizeof(phdr)); tmp += sizeof(phdr);/ Remove unwanted PT_NOTE program headers. // (1.5.6) 移除掉已经无用的 PT_NOTE 掌握构造 / i = (nr_ptnote - 1) sizeof(Elf64_Phdr); elfsz = elfsz - i; memmove(tmp, tmp+i, ((elfsz)-sizeof(Elf64_Ehdr)-sizeof(Elf64_Phdr)));memset(elfptr + elfsz, 0, i); elfsz = roundup(elfsz, PAGE_SIZE);/ Modify e_phnum to reflect merged headers. / ehdr_ptr->e_phnum = ehdr_ptr->e_phnum - nr_ptnote + 1;/ Store the size of all notes. We need this to update the note header when the device dumps will be added. / elfnotes_orig_sz = phdr.p_memsz;return 0;}读取 elf core (运行在 crash kernel)

经由上一节的解析 elf 头数据基本已准备好，elfcorebuf 用来存储 elf header + elf program header，elfnotes_buf 用来存储 PT_NOTE segment。

现在可以通过对 /proc/vmcore 文件的读操作来读取 elf core 数据了：

static const struct proc_ops vmcore_proc_ops = { .proc_read = read_vmcore, .proc_lseek = default_llseek, .proc_mmap = mmap_vmcore,};↓read_vmcore()↓static ssize_t __read_vmcore(char buffer, size_t buflen, loff_t fpos,int userbuf){ssize_t acc = 0, tmp;size_t tsz; u64 start;struct vmcore m = ;if (buflen == 0 || fpos >= vmcore_size)return 0;/ trim buflen to not go beyond EOF /if (buflen > vmcore_size - fpos) buflen = vmcore_size - fpos;/ Read ELF core header // (1) 从 elfcorebuf 中读取 elf header + elf program header，并拷贝给给用户态读内存 /if (fpos < elfcorebuf_sz) { tsz = min(elfcorebuf_sz - (size_t)fpos, buflen);if (copy_to(buffer, elfcorebuf + fpos, tsz, userbuf))return -EFAULT; buflen -= tsz; fpos += tsz; buffer += tsz; acc += tsz;/ leave now if filled buffer already /if (buflen == 0)return acc; }/ Read Elf note segment // (2) 从 elfnotes_buf 中读取 PT_NOTE segment，并拷贝给给用户态读内存 /if (fpos < elfcorebuf_sz + elfnotes_sz) {void kaddr;/ We add device dumps before other elf notes because the other elf notes may not fill the elf notes buffer completely and we will end up with zero-filled data between the elf notes and the device dumps. Tools will then try to decode this zero-filled data as valid notes and we don't want that. Hence, adding device dumps before the other elf notes ensure that zero-filled data can be avoided. /#ifdef CONFIG_PROC_VMCORE_DEVICE_DUMP/ Read device dumps /if (fpos < elfcorebuf_sz + vmcoredd_orig_sz) { tsz = min(elfcorebuf_sz + vmcoredd_orig_sz - (size_t)fpos, buflen); start = fpos - elfcorebuf_sz;if (vmcoredd_copy_dumps(buffer, start, tsz, userbuf))return -EFAULT; buflen -= tsz; fpos += tsz; buffer += tsz; acc += tsz;/ leave now if filled buffer already /if (!buflen)return acc; }#endif / CONFIG_PROC_VMCORE_DEVICE_DUMP // Read remaining elf notes / tsz = min(elfcorebuf_sz + elfnotes_sz - (size_t)fpos, buflen); kaddr = elfnotes_buf + fpos - elfcorebuf_sz - vmcoredd_orig_sz;if (copy_to(buffer, kaddr, tsz, userbuf))return -EFAULT; buflen -= tsz; fpos += tsz; buffer += tsz; acc += tsz;/ leave now if filled buffer already /if (buflen == 0)return acc; }/ (3) 从 vmcore_list 链表中读取 PT_LOAD segment，并拷贝给给用户态读内存 对物理地址进行ioremap_cache() 建立映射往后才能读取 / list_for_each_entry(m, &vmcore_list, list) {if (fpos < m->offset + m->size) { tsz = (size_t)min_t(unsigned long long, m->offset + m->size - fpos, buflen); start = m->paddr + fpos - m->offset; tmp = read_from_oldmem(buffer, tsz, &start, userbuf, mem_encrypt_active());if (tmp < 0)return tmp; buflen -= tsz; fpos += tsz; buffer += tsz; acc += tsz;/ leave now if filled buffer already /if (buflen == 0)return acc; } }return acc;}
