phpuvc协定技巧_Authing Share｜理解 SAML2 协议

SAML2 综述

安全断言标记措辞（英语：Security Assertion Markup Language，简称SAML，发音 sam-el）是一个基于 XML 的开源标准数据格式，它在当事方之间交流身份验证和授权数据，尤其是在身份供应者和做事供应者之间交流。
SAML2.0 可以实现基于网络跨域的单点登录（SSO）， 以便于减少向一个用户分发多个身份验证令牌的管理开销。

在 SAML 协议中，涉及两个主体：

Service Provider 做事供应方，简称 SP。
什么是做事供应方？例如：阿里云掌握台、腾讯云掌握台、AWS 掌握台这些都是做事供应方。

Identity Provider 身份供应方，简称 IdP。
什么是身份供应方？Authing 可以作为身份供应方，身份供应方能够向 SP 发送身份断言，所谓身份断言便是由 Authing 签发的，可以标识某个人身份的 Token，只不过，在 SAML 协议中，这个 Token 的格式是 XML 形式的。
还有一些其他的身份供应方，例如 Okta、SSOCircle、Auth0，他们都可以向 SP 返转身份断言。

两个主体通过用户的浏览器进行信息交流。
办法上，SP 可以返回带参数的重定向 HTTP 相应，让用户急速通过参数将信息发给 IdP。
而 IdP 会返回一个表单，同时还有一段立即提交表单的 JS 代码，从而让用户急速将信息发给 SP。

总结一下，SP 供应做事，须要知道用户的身份，就须要向 IdP 讯问。
IdP 知道用户的身份，当用户在 IdP 登录成功，IdP 就将用户的身份以 SAML 断言的形式发给 SP。
SP 信赖 IdP 发来的身份断言，从而授予该用户在 SP 的干系权限。

当用户的身份无法鉴定时，SP 会向 IdP 发送 SAML Request 信息（通过浏览器发送），要求 IdP 来鉴定用户身份。

由阿里云掌握台发起一次 SAML Request 的形式是这样的：

GET https://core.authing.cn/v2/api/saml-idp/5e10927e4ecfd464fb4edaf6?SAMLRequest=fZJLT%2BMwFIX3%2FIrI%2B7yct9Wk6kyFQGJERQKL2RnnJnWV2Blfp2L%2BPaGlDLOApaV7vnN0jlfrl3FwjmBQalWS0AuIA0roVqq%2BJI%2FNtZuTdXW1Qj4OdGKb2e7VA%2FyZAa2zQQRjF91PrXAewdRgjlLA48NdSfbWTsh8H2WvpPL4IP%2FOyhN69N9Qfl3fE2e7UKTi9mR9EQhtwOOLz5LAE8o%2FUp9P8qRyZTv5CYRBQTOIQXRtnMbdcwwt71LiXGsj4JSwJB0fEIhzuy0Jp9AXgvaHgwzzPA%2FjfXagbRYlebeP%2BmI5wh1HlEf4J0Oc4Vah5cqWhAY0cIPCpXkTRiwoWJJ5eZH%2BJs7OaKuFHn5IdS5sNoppjhKZ4iMgs4LVm193jHoBez4fIbtpmp27u68b4jxdiqdvxS9TKGTnqr9nTe%2FGpDovw06JzWfC9wB%2B2Y5UXy8VRlmcpkWUpUlGY5p8TLfyP7tW78%2F%2Fv0f1Cg%3D%3D

(提示：代码可向右滑动)

SAMLRequest 参数通过 query 在 URL 中发送给 IdP，SAMLRequest 的内容如下：

fZJLT+MwFIX3/IrI+7yct9Wk6kyFQGJERQKL2RnnJnWV2Blfp2L+PaGlDLOApaV7vnN0jlfrl3FwjmBQalWS0AuIA0roVqq+JI/NtZuTdXW1Qj4OdGKb2e7VA/yZAa2zQQRjF91PrXAewdRgjlLA48NdSfbWTsh8H2WvpPL4IP/OyhN69N9Qfl3fE2e7UKTi9mR9EQhtwOOLz5LAE8o/Up9P8qRyZTv5CYRBQTOIQXRtnMbdcwwt71LiXGsj4JSwJB0fEIhzuy0Jp9AXgvaHgwzzPA/jfXagbRYlebeP+mI5wh1HlEf4J0Oc4Vah5cqWhAY0cIPCpXkTRiwoWJJ5eZH+Js7OaKuFHn5IdS5sNoppjhKZ4iMgs4LVm193jHoBez4fIbtpmp27u68b4jxdiqdvxS9TKGTnqr9nTe/GpDovw06JzWfC9wB+2Y5UXy8VRlmcpkWUpUlGY5p8TLfyP7tW78//v0f1Cg==

(提示：代码可向右滑动)

base64 decode + inflate 解码后

（https://www.samltool.com/decode.php）

<?xml version="1.0" encoding="UTF-8"?><saml2p:AuthnRequest AssertionConsumerServiceURL="https://signin.aliyun.com/saml/SSO" Destination="https://core.authing.cn/v2/api/saml-idp/5e10927e4ecfd464fb4edaf6" ForceAuthn="false" ID="a2eg9c2gjji188814h7j2d7358fh3g9" IsPassive="false" IssueInstant="2020-09-28T13:09:57.896Z" ProtocolBinding="urn:oasis:names:tc:SAML:2.0:bindings:HTTP-POST" Version="2.0" xmlns:saml2p="urn:oasis:names:tc:SAML:2.0:protocol"> <saml2:Issuer xmlns:saml2="urn:oasis:names:tc:SAML:2.0:assertion">https://signin.aliyun.com/1374669376572425/saml/SSO </saml2:Issuer></saml2p:AuthnRequest>

(提示：代码可向右滑动)

IdP 收到 SAML Request 后，会弹出登录框对用户身份进行认证：

当用户在 IdP 完成登录后，SAML IdP 将用户身份断言发送给 SP（放在表单中，通过浏览器 POST 要求发送）。
SAML IdP 的相应内容如下：

<form id="saml-form" method="post" action="https://signin.aliyun.com/saml/SSO" autocomplete="off"> <input type="hidden" name="SAMLResponse" id="saml-response" value="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" /> <input type="hidden" name="RelayState" id="relay-state" value="" /></form><script type="text/javascript"> (function() { document.forms[0].submit(); })();</script>

(提示：代码可向右滑动)

没有什么神秘的，便是一个 HTML form 表单和一段立即提交该表单的 JS 代码。
个中的 SAML Response 信息如下：

base64 decode + inflate 解码后

(https://www.samltool.com/decode.php)

<samlp:Response xmlns:samlp="urn:oasis:names:tc:SAML:2.0:protocol" xmlns:saml="urn:oasis:names:tc:SAML:2.0:assertion" ID="_62b177c1-a919-42f6-9586-47f13b71081f" Version="2.0" IssueInstant="2020-09-28T13:30:31.788Z" Destination="https://signin.aliyun.com/saml/SSO" InResponseTo="a49f8edi31cj0a2a459g0331c3d9c10"> <saml:Issuer>https://20nqulvoqpbp.authing.cn</saml:Issuer> <samlp:Status> <samlp:StatusCode Value="urn:oasis:names:tc:SAML:2.0:status:Success"/> </samlp:Status> <saml:Assertion xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:saml="urn:oasis:names:tc:SAML:2.0:assertion" ID="_fae95b47-cbf3-4a20-add0-99d856b4124e" Version="2.0" IssueInstant="2020-09-28T13:30:31.788Z"> <saml:Issuer>https://20nqulvoqpbp.authing.cn</saml:Issuer> <ds:Signature xmlns:ds="http://www.w3.org/2000/09/xmldsig#"> <ds:SignedInfo> <ds:CanonicalizationMethod Algorithm="http://www.w3.org/2001/10/xml-exc-c14n#"/> <ds:SignatureMethod Algorithm="http://www.w3.org/2000/09/xmldsig#rsa-sha1"/> <ds:Reference URI="#_fae95b47-cbf3-4a20-add0-99d856b4124e"> <ds:Transforms> <ds:Transform Algorithm="http://www.w3.org/2000/09/xmldsig#enveloped-signature"/> <ds:Transform Algorithm="http://www.w3.org/2001/10/xml-exc-c14n#"/> </ds:Transforms> <ds:DigestMethod Algorithm="http://www.w3.org/2000/09/xmldsig#sha1"/> <ds:DigestValue>/ol6lC1j+smdonl48+lJTzUeqnw=</ds:DigestValue> </ds:Reference> </ds:SignedInfo> <ds:SignatureValue>awzcE0dp8BzTW4b4PFaRX7NKOC95bLqOnPeAKI/CsDfGaJdmzCK0fVliz+e6XzBluKfBpQtrQonKl7k2vVNaPFx9PpSVzwK91HLGvYQ0qB36uA4HFvm/3M31DL3ZRFPRq68ZaVAG6lMVd0YbiInVv9FWwsi+6jEpF+PRlmkoqAI=</ds:SignatureValue> <ds:KeyInfo> <ds:X509Data> <ds:X509Certificate>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</ds:X509Certificate> </ds:X509Data> </ds:KeyInfo> </ds:Signature> <saml:Subject> <saml:NameID Format="urn:oasis:names:tc:SAML:1.1:nameid-format:unspecified">yezuwei@authing.onaliyun.com</saml:NameID> <saml:SubjectConfirmation Method="urn:oasis:names:tc:SAML:2.0:cm:bearer"> <saml:SubjectConfirmationData NotOnOrAfter="2020-09-28T14:30:31.788Z" Recipient="https://signin.aliyun.com/saml/SSO" InResponseTo="a49f8edi31cj0a2a459g0331c3d9c10"/> </saml:SubjectConfirmation> </saml:Subject> <saml:Conditions NotBefore="2020-09-28T13:30:31.788Z" NotOnOrAfter="2020-09-28T14:30:31.788Z"> <saml:AudienceRestriction> <saml:Audience>https://signin.aliyun.com/1374669376572425/saml/SSO</saml:Audience> </saml:AudienceRestriction> </saml:Conditions> <saml:AuthnStatement AuthnInstant="2020-09-28T13:30:31.888Z" SessionIndex="ooeumcq6eHjddr1H3Fyzou7Cs-OGTsNl"> <saml:AuthnContext> <saml:AuthnContextClassRef>urn:oasis:names:tc:SAML:2.0:ac:classes:unspecified</saml:AuthnContextClassRef> </saml:AuthnContext> </saml:AuthnStatement> <saml:AttributeStatement> <saml:Attribute Name="email" NameFormat="urn:oasis:names:tc:SAML:2.0:attrname-format:basic"> <saml:AttributeValue xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:type="xs:string">yezuwei@authing.cn </saml:AttributeValue> </saml:Attribute> <saml:Attribute Name="name" NameFormat="urn:oasis:names:tc:SAML:2.0:attrname-format:basic"> <saml:AttributeValue xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:type="xs:string"/> </saml:Attribute> <saml:Attribute Name="username" NameFormat="urn:oasis:names:tc:SAML:2.0:attrname-format:basic"> <saml:AttributeValue xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:type="xs:string">yezuwei@authing.cn </saml:AttributeValue> </saml:Attribute> <saml:Attribute Name="phone" NameFormat="urn:oasis:names:tc:SAML:2.0:attrname-format:basic"> <saml:AttributeValue xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:type="xs:string">null </saml:AttributeValue> </saml:Attribute> </saml:AttributeStatement> </saml:Assertion> </samlp:Response>

(提示：代码可向右滑动)

这段内容便是用户的身份断言，也便是用户的 Token，只不过这个 Token 通过 XML 格式通报。

读到这里，你可能会对 SP、IdP 如何处理这些冗长的 XML 信息感到困惑。
Authing 会办理这些繁琐的处理，而你只需关注如何精确地配置 Authing IdP，与 SAML SP 进行通信。

本文为读者讲述 SAML 中，SP、IdP、浏览器三个实体之间数据交互的流程。

利用 SAML 协议进行身份认证时，涉及到以下三个主体

SP 与 IdP 之间的通信办法分为 HTTP Redirect Binding、HTTP POST Binding、HTTP Artifact Binding。
每种办法在不同的阶段会用不同类型的 HTTP 与对方通信。

SP 通过重定向 GET 要求把 SAML Request 发送到 IdP，IdP 通过立即提交的 Form 表单以 POST 要求的办法将 SAML Response 发到 SP。

HTTP POST Binding

IdP 通过立即提交的 Form 表单以 POST 要求的办法将 SAML Request 发到 SP。
IdP 通过立即提交的 Form 表单以 POST 要求的办法将 SAML Response 发到 SP。

HTTP Artifact Binding

SP、IdP 双方只通过浏览器交流 SAML Request、SAML Response 的索引编号，收到编号后，在后端要求对方的 Artifact Resolution Service 接口来获取真正的要求实体内容。
从而避免 SAML Request、SAML Response 暴露在前端。
