支持版本：Mastercam2022
如需其他版本，跟帖留言
Mastercam后处理输刀具清单出加工韶光加工深度的后处理功能
本后处理基于大家所熟习的经典4轴后处理为根本，新增功能如下：
1：增加程序头输出全局X，Y，Z最大最小范围，此功能中的每一个数据均可独立关闭。
开关如下：
oneZone_oal_min_x : yes$ oneZone_oal_max_x : yes$ oneZone_oal_min_y : yes$oneZone_oal_max_y : yes$ oneZone_oal_min_z : yes$ oneZone_oal_max_z : yes$
2：增加刀具清单输出加工预留量，同时如预留量为0，则不输出，此功能可关闭。
开关如下：
oneZone_stock_to_table : yes$
3：增加每个操作输出加工预余量，同时如预留量为0，则不输出，此功能可独立关闭。
开关如下：
oneZone_stock_to_leave : yes$
4：增加刀具清单输出刀具的最大加工深度。见本文后面的实例代码
5：增加刀具清单输出刀具的加工韶光。见本文后面的实例代码
6：增加输出每个操作的加工韶光。
7：刀具清单支持用户定义部分数据及数据顺序。
8：输出的加工韶光支持用户定义输出格式。
9：每个操作的输出信息支持用户定义格式。
10：全体刀具清单支持开关，
开关如下：
tool_info : 2
11：后处理增加了相应的标识，标识如下：
以下数据后处理中会利用到，请勿随意修正或删除，屏蔽，否则后处理将会报错。
#dot not delete below two line license : 279497172slicense_marks : "oneZone"
12：其他功能未逐一列出。
13：输出操作顺序号为OP#
14：更多功能自行挖掘。
以下为输出样板代码
O0000 (Cutting_Testing)(MCX FILE - G:\NC_OUTPUT\CUTTING_TESTING.MCAM)(PROGRAM - Cutting_Testing.NC)(DATE - APR-05-2022)(TIME - 10:58 PM)(TOTAL CYCLE TIME-> 7H:14M:37S)(---TOOL TABLE---)( T1 | EM D50 R0.8 | H1 | D1 | DIA50. | | | Z-MIN: 19.05 | 19M:19S )( T10 | EM D16R0.855100 | H10 | D10 | DIA16. | WALL STOCK MAX: .6, | FLOOR STOCK MAX: .3, | Z-MIN: -.125 | 1H:47M:44S )( T11 | EM D12R1.61575 | H11 | D11 | DIA12. | WALL STOCK MIN: .6, WALL STOCK MAX: .6, | FLOOR STOCK MAX: .3, | Z-MIN: 3.475 | 1H:47M:14S )( T12 | EM D10R2.53575 | H12 | D12 | DIA10. | WALL STOCK MIN: .6, WALL STOCK MAX: .7, | FLOOR STOCK MIN: .3, FLOOR STOCK MAX: .3, | Z-MIN: 3.475 | 1M:41S )( T13 | EM D12R2.540100 | H13 | D13 | DIA12. | WALL STOCK MAX: 3., | FLOOR STOCK MAX: .5, | Z-MIN: 3.175 | 1H:19M:17S )( T2 | SPOT D890 | H2 | D2 | DIA8. | Z-MIN: 17.55 | 21S )( T14 | DR D5.12560 | H14 | D14 | DIA5.1 | Z-MIN: 7.993 | 4S )( T15 | EM D12R03048.75 | H15 | D15 | DIA12. | | | Z-MIN: 0. | 20M:1S )( T16 | CF D89060 | H16 | D16 | DIA8. | | | Z-MIN: 17.925 | 1H:38M:56S )(Post For oneZone)(OAL MAX = X:120.574 Y:439.979 Z:60. )(OAL MIN = X:-126.498 Y:-389.979 Z:-.125 )N5 G00 G17 G21 G40 G80 G90N10 G91 G28 Z0.N15 (COMPENSATION TYPE - COMPUTER)(OP#1 Z-MIN: 19.05 CYCLE TIME-> 19M:19S)N20 T1 M06 (EM D50 R0.8)N25 G00 G17 G90 G56 X-13.727 Y414.979 S12000 M03N30 G43 H1 Z60. M08N35 Z21.05N40 G94 G01 Z19.05 F315.N45 X-38.727 Y389.785N50 Y363.39N233 N234 N235 Y-307.304N240 G00 Z60. M09N245 M05N250 G91 G28 Z0.N255 M01N260 (COMPENSATION TYPE - COMPUTER)(OP#2 Z-MIN: 8.89 CYCLE TIME-> 2M:28S)( WALL STOCK: .6 )N265 T10 M06 (EM D16R0.855100)N270 G00 G17 G90 G56 X-124.498 Y224.575 S9600 M03N275 G43 H10 Z60. M08N280 Z21.05N285 G94 G01 Z15.663 F204.7N495 G01 X-123.069N500 G03 X-123.347 Y299.298 I0. J-1.6N505 G01 X-126.498 Y298.742N510 G00 Z60.(OP#3 Z-MIN: 6.65 CYCLE TIME-> 47S)( FLOOR STOCK: .3 )N515 X-124.498 Y226.515N520 Z10.89N525 G01 Z6.65N530 X-121.347 Y225.959N535 G03 X-121.069 Y225.935 I.278 J1.576N540 G01 X-76.173N545 Y276.177N550 G03 X-78.079 Y278.322 I-2.16 J0.N555 G02 X-97.246 Y287.526 I3.861 J32.601N560 X-118.598 Y297.382 I-3.536 J20.396N565 G01 X-123.069N570 G03 X-123.347 Y297.358 I0. J-1.6N575 G01 X-126.498 Y296.802N580 G00 Z60.(OP#4 Z-MIN: -.125 CYCLE TIME-> 3M:29S)( WALL STOCK: .6 )N585 X-49.954 Y-303.564N590 Z21.05N595 G01 Z20.05N1260 G03 X-50.059 Y-300.762 I-.936 J4.057N1265 X-48.187 Y-308.876 I.936 J-4.057N1270 G00 Z60. M09N1275 M05N1280 G91 G28 Z0.N1285 M01
